Paint Pixels 7 With JPG Saves And No Gaps In Drawing And Thicker Drawing!

[bplus]

I admit that color picker is confusing, the box at the bottom should Simply and Only show the current color selected.

I will fix up after getting this Tree Maker settled and the dog walked.

@SierraKen

I haven't checked yet but sounds like you have File Dialog working, I will assume you like very much ;-))
The BM file had a 2nd routine for file save AS, I hope that is what you found and didn't have to go through a bunch of extra work.

[SierraKen]

Thanks B+. Nah I didn't change the BM file. I just added one line of code to automatically rename it to a jpg file if it wasn't already one.
I made many more small fixes since my last post, including thicker Ray lines. I'll wait until you are done with your color picker before I make a new zip file, but here's the code you can use. I'll add a picture of the thicker ray lines used with your fill-in code example in the attachments.


Update: Huge memory issue found, please delete this version if you have it. Code has been removed.

[bplus]

@SierraKen

OK I left the colorDialog$ Function in the tester sub in case you want to play with settings yourself, otherwise just replace the function with this one. I don't think I messed with slider code.

I have made changes besides the giant color sample color box (not so pretty but not so confusing either):
1. Moved Color Dialogue to screen _middle
2. gave the test sample box a black background color, so the sample color is over black, keep that in mind when changing alpha = transparency
3. I defaulted alpha to full opaque 255, maybe some or mostly want solid color.

Color Dialog in tester:

Code: QB64: [Select]

1. _TITLE "Color Dialog rev 2020-06-27" 'b+ 2020-06-27
2. SCREEN _NEWIMAGE(400, 300, 32)
3. _DELAY .25
4. _SCREENMOVE _MIDDLE
5.
6. WHILE _KEYDOWN(27) = 0
7.     CLS
8.     k~& = VAL(colorDialog$)
9.     PRINT "Color is: "; k~&
10.     LINE (20, 40)-(_WIDTH - 20, _HEIGHT - 20), k~&, BF
11.     _DELAY 2
12. WEND
13.
14. FUNCTION colorDialog$
15.
16.     'first screen dimensions items to restore at exit
17.     DIM curRow AS INTEGER, curCol AS INTEGER, autoDisplay AS INTEGER
18.     DIM sw AS INTEGER, sh AS INTEGER, fg AS _UNSIGNED LONG, bg AS _UNSIGNED LONG
19.     DIM curScrn AS LONG, backScrn AS LONG 'some handles
20.
21.     DIM cd AS LONG
22.     DIM r AS INTEGER, g AS INTEGER, b AS INTEGER, a AS INTEGER, mb AS INTEGER, mx AS INTEGER, my AS INTEGER, i AS INTEGER
23.     DIM makeConst$, k$
24.     DIM f AS SINGLE
25.
26.     'save old settings to restore at end ofsub
27.     curRow = CSRLIN
28.     curCol = POS(0)
29.     autoDisplay = _AUTODISPLAY
30.     sw = _WIDTH
31.     sh = _HEIGHT
32.     fg = _DEFAULTCOLOR
33.     bg = _BACKGROUNDCOLOR
34.     _KEYCLEAR
35.     'screen snapshot
36.     curScrn = _DEST
37.     backScrn = _NEWIMAGE(sw, sh, 32)
38.     _PUTIMAGE , curScrn, backScrn
39.
40.     cd = _NEWIMAGE(800, 600, 32)
41.     SCREEN cd
42.     _DELAY .25
43.     _SCREENMOVE _MIDDLE
44.     r = 128: g = 128: b = 128: a = 255
45.     COLOR &HFFDDDDDD, &HFF000000
46.     DO
47.         CLS
48.         makeConst$ = "&H" + RIGHT$(STRING$(8, "0") + HEX$(_RGBA32(r, g, b, a)), 8)
49.         COLOR &HFFDDDDDD, 0
50.         slider 16, 10, r, "Red"
51.         slider 16, 60, g, "Green"
52.         slider 16, 110, b, "Blue"
53.         slider 16, 160, a, "Alpha"
54.         COLOR &HFFDDDDDD, &HFF000000
55.         _PRINTSTRING (150, 230), "Current Color Setting is shown below (Alphas on Black Background)"
56.         _PRINTSTRING (150, 260), "Press Enter or Spacebar, if you want to use the color: " + makeConst$
57.         _PRINTSTRING (210, 280), "Press Escape or Q to not use any color, returns 0."
58.         LINE (90, 300)-(710, 590), &HFF000000, BF
59.         LINE (90, 300)-(710, 590), VAL(makeConst$), BF
60.         WHILE _MOUSEINPUT: WEND
61.         mb = _MOUSEBUTTON(1)
62.         IF mb THEN 'clear it
63.             mx = _MOUSEX: my = _MOUSEY
64.             IF mx >= 16 AND mx <= 781 THEN
65.                 IF my >= 10 AND my <= 50 THEN
66.                     r = INT((mx - 16) / 3)
67.                 ELSEIF my >= 60 AND my <= 100 THEN
68.                     g = INT((mx - 16) / 3)
69.                 ELSEIF my >= 110 AND my <= 150 THEN
70.                     b = INT((mx - 16) / 3)
71.                 ELSEIF my >= 160 AND my <= 200 THEN
72.                     a = INT((mx - 16) / 3)
73.                 END IF
74.             END IF
75.         END IF
76.         k$ = INKEY$
77.         IF LEN(k$) THEN
78.             IF ASC(k$) = 27 OR k$ = "q" THEN EXIT DO
79.             IF ASC(k$) = 13 OR k$ = " " THEN colorDialog$ = makeConst$: EXIT DO
80.         END IF
81.         _DISPLAY
82.         _LIMIT 60
83.     LOOP
84.
85.     'put things back
86.     SCREEN curScrn
87.     COLOR _RGB32(255, 255, 255), _RGB32(0, 0, 0): CLS
88.     _PUTIMAGE , backScrn
89.     _DISPLAY
90.     COLOR fg, bg
91.     _FREEIMAGE backScrn
92.     _FREEIMAGE cd
93.     IF autoDisplay THEN _AUTODISPLAY
94.     'clear key presses
95.     _KEYCLEAR
96.     'clear mouse clicks
97.     WHILE _MOUSEINPUT: WEND
98.     mb = _MOUSEBUTTON(1)
99.     IF mb THEN 'clear it
100.         WHILE mb 'OK!
101.             IF _MOUSEINPUT THEN mb = _MOUSEBUTTON(1)
102.             _LIMIT 10
103.         WEND
104.     END IF
105.     LOCATE curRow, curCol
106.
107. END FUNCTION
108.
109. SUB slider (x, y, value, label$)
110.     DIM c~&, s$
111.     SELECT CASE label$
112.         CASE "Red": c~& = &HFFFF0000
113.         CASE "Green": c~& = &HFF008800
114.         CASE "Blue": c~& = &HFF0000FF
115.         CASE "Alpha": c~& = &H88FFFFFF
116.     END SELECT
117.     LINE (x, y)-STEP(765, 40), c~&, B
118.     LINE (x, y)-STEP(3 * value, 40), c~&, BF
119.     s2$ = STR$(value)
120.     s3$ = LTRIM$(RTRIM$(s2$))
121.     s$ = label$ + " = " + s3$
122.     _PRINTSTRING (x + 384 - 4 * LEN(s$), y + 12), s$
123. END SUB
124.
125.

We could go back to that pretty color box, the user clicks a point and that becomes the color picked.

That is like killing 3 sliders with one click! ;-))

(That is maybe what TempodiBasic thought was supposed to happen.)

[SierraKen]

The new color picker works GREAT! Thanks! One thing though I should mention is that for some reason the Fill-in Sub sometimes doesn't gets used when it needs it. I tested that by putting a PRINT "test" in the Sub and sometimes it just won't do anything. I thought maybe it has to wait until the other one is finished but I don't think that's the case because I wait a bit longer and sometimes it still doesn't work. When I added the different colors to the Sub I might have messed it up, I don't know. Can you check it for me? Here is the code. Oh by the way, I think the 3 Sliders is an awesome thing because it helps the user get in control of exactly what color they want, instead of just guessing on a click.

The first section:

Code: QB64: [Select]

1.     'Here is Fill-In
2.     IF a$ = "f" OR a$ = "F" THEN
3.         fMode = 1 - fMode
4.         m = 6
5.         IF fMode THEN lastx = mousex: lastY = mousey
6.     END IF
7.     IF fMode AND m = 6 THEN
8.         _TITLE "Mode: (F)ill | (D)raw, (E)rase, 1 = New, (C)olors, (R)ays, (O)rbits, (B)oxes, (S)ave, (L)oad, (P)rint"
9.         IF mouseLeftButton THEN paint3 lastx, lastY, clr~&, &HFFFFFFFF
10.         lastx = mousex
11.         lastY = mousey
12.         _PUTIMAGE , s&, picture&
13.     END IF
14.

Here is the Sub itself:

Code: QB64: [Select]

1. SUB paint3 (x0, y0, clr~&, fill AS _UNSIGNED LONG) ' needs max, min functions
2.     DIM fillColor AS _UNSIGNED LONG, W, H, parentF, tick, ystart, ystop, xstart, xstop, x, y
3.     fillColor = POINT(x0, y0)
4.     W = _WIDTH - 1: H = _HEIGHT - 1
5.     DIM temp(W, H)
6.     temp(x0, y0) = 1: parentF = 1
7.     PSET (x0, y0), clr~&
8.     WHILE parentF = 1
9.         parentF = 0: tick = tick + 1
10.         ystart = max(y0 - tick, 0): ystop = min(y0 + tick, H)
11.         y = ystart
12.         WHILE y <= ystop
13.             xstart = max(x0 - tick, 0): xstop = min(x0 + tick, W)
14.             x = xstart
15.             WHILE x <= xstop
16.                 IF POINT(x, y) = fillColor AND temp(x, y) = 0 THEN
17.                     IF temp(max(0, x - 1), y) THEN
18.                         temp(x, y) = 1: parentF = 1: PSET (x, y), clr~&
19.                     ELSEIF temp(min(x + 1, W), y) THEN
20.                         temp(x, y) = 1: parentF = 1: PSET (x, y), clr~&
21.                     ELSEIF temp(x, max(y - 1, 0)) THEN
22.                         temp(x, y) = 1: parentF = 1: PSET (x, y), clr~&
23.                     ELSEIF temp(x, min(y + 1, H)) THEN
24.                         temp(x, y) = 1: parentF = 1: PSET (x, y), clr~&
25.                     END IF
26.                 END IF
27.                 x = x + 1
28.             WEND
29.             y = y + 1
30.         WEND
31.     WEND
32. END SUB
33.

Oh, and here are the 2 tiny Functions.

Code: QB64: [Select]

1. FUNCTION min (n1, n2)
2.     IF n1 > n2 THEN min = n2 ELSE min = n1
3. END FUNCTION
4.
5. FUNCTION max (n1, n2)
6.     IF n1 < n2 THEN max = n2 ELSE max = n1
7. END FUNCTION
8.

[SierraKen]

I just changed one line from lastx, lasty to mousex, mousey. But it still does the same thing sometimes.

Code: QB64: [Select]

1. IF mouseLeftButton THEN paint3 mousex, mousey, clr~&, &HFFFFFFFF
2.

[bplus]

I checked fill from code in reply #16


Looks OK

Remember fill only fills all color around it that is exactly the same as point you click.

If you try fill over photo where nearly every color is different you will want to fill to a border color, draw the border and then use PAINT (x, y), fillColor, toBorderColor

Wait....


Why are there 4 parameters in PAINT3? It should look like this:

Code: QB64: [Select]

1. SUB paint3 (x0, y0, fill AS _UNSIGNED LONG) ' needs max, min functions
2.     DIM fillColor AS _UNSIGNED LONG, W, H, parentF, tick, ystart, ystop, xstart, xstop, x, y
3.     fillColor = POINT(x0, y0)
4.     'PRINT fillColor
5.     W = _WIDTH - 1: H = _HEIGHT - 1
6.     DIM temp(W, H)
7.     temp(x0, y0) = 1: parentF = 1
8.     PSET (x0, y0), fill
9.     WHILE parentF = 1
10.         parentF = 0: tick = tick + 1
11.         ystart = max(y0 - tick, 0): ystop = min(y0 + tick, H)
12.         y = ystart
13.         WHILE y <= ystop
14.             xstart = max(x0 - tick, 0): xstop = min(x0 + tick, W)
15.             x = xstart
16.             WHILE x <= xstop
17.                 IF POINT(x, y) = fillColor AND temp(x, y) = 0 THEN
18.                     IF temp(max(0, x - 1), y) THEN
19.                         temp(x, y) = 1: parentF = 1: PSET (x, y), fill
20.                     ELSEIF temp(min(x + 1, W), y) THEN
21.                         temp(x, y) = 1: parentF = 1: PSET (x, y), fill
22.                     ELSEIF temp(x, max(y - 1, 0)) THEN
23.                         temp(x, y) = 1: parentF = 1: PSET (x, y), fill
24.                     ELSEIF temp(x, min(y + 1, H)) THEN
25.                         temp(x, y) = 1: parentF = 1: PSET (x, y), fill
26.                     END IF
27.                 END IF
28.                 x = x + 1
29.             WEND
30.             y = y + 1
31.         WEND
32.     WEND
33. END SUB

When you call it inside your program
PAINT3 mousex, mousey, colorToFillInWith '< the color selected off picker

No 4th argument!

[SierraKen]

The more you use it on one image, the lesser it works on my end. The first few times it works fine. But if you use it like over 5 times, every other time it doesn't work, and sometimes it only works every few times. So please try it again. Make a big scribble and try it about 10 times. If it works perfectly on your end, then something is off. By the way, my QB64 version is 1.3 still. I think it's time to get 1.4.

[bplus]

No I see you mucked up PAINT3, only 3 arguments in the call.

It's a wonder it works at all?

OK new Color Picker and PAINT3 returned to 3 arguments and yes, I see what you mean. After awhile the clicks don't work or only rarely.

EDIT: Sorry wrong copy posted, seems I lost track of proper mod.

[SierraKen]

Bplus, yours doesn't work with a white background. And yours only produces a white fill-in. So I had to add the current color variable to it. Maybe I did mess it up, but that's why I'm asking you.

[SierraKen]

Here it is with your SUB... try it out..


Update: Huge memory issue found, please delete this version if you have it. Code has been removed.

[bplus]

Yeah I plugged in the old PAINT3 and new Color Picker and see what you mean about clicks not working after awhile.

I updated here: https://www.qb64.org/forum/index.php?topic=2751.msg119938#msg119938

BTW your orbits and boxes work funny too?

But I do like the thicker lines, that's new right?

[SierraKen]

Thanks for adding the color. Well, I never changed your orbits and boxes. But they work good for me. This isn't a professional app :).
But yeah, the Fill-In still has the same problem of not working sometimes. I don't know if there's a fix for this or not. I wonder if it's trying to squeeze in between points and filling up other stuff, because I did notice that one shade of an already-existing fill-in changed color a tiny bit when I used the fill-in on a different place. If you think I should just remove the fill-in that's OK with me. I'm just having fun with this. Oh and yeah I made the lines thicker earlier today. I like them too. :) Those and the open and save windows dialog totally made my weekend.

[bplus]

Dang it I posted wrong code here:
https://www.qb64.org/forum/index.php?topic=2751.msg119938#msg119938

It has your paint3, I am getting confused... I know PAINT3 works if you don't mess with parameters and it's innards.

You could check if you have a shared variable that PAINT3 might be changing or be change by but I doubt you share variables that much.

What is difference between your oldx, oldy and lastx, lasty?

[bplus]

Code: QB64: [Select]

1.     IF fMode AND m = 6 THEN
2.         _TITLE "Mode: (F)ill | (D)raw, (E)rase, 1 = New, (C)olors, (R)ays, (O)rbits, (B)oxes, (S)ave, (L)oad, (P)rint"
3.         IF mouseLeftButton THEN paint3 mousex, mousey, &HFFFFFFFF '<<<<<<<<<<<<<< no use the users Clr~& pick
4.         lastx = mousex
5.         lastY = mousey
6.         _PUTIMAGE , s&, picture&
7.     END IF

[SierraKen]

I don't know why, but without that HFFFFFF, it makes a Syntax Error.
When I do this:

Code: QB64: [Select]

1. IF mouseLeftButton THEN paint3 mousex, mousey, clr~&
2.
