Re: The Cobalt Spinner
« Reply #15 on: July 19, 2020, 08:50:30 pm »
Very nice Steve! I like the unique old fashioned feeling to it.
Logged

Offline bplus

  • Global Moderator
  • Forum Resident
  • Posts: 8053
  • b = b + ...
    • View Profile
Re: The Cobalt Spinner
« Reply #16 on: July 19, 2020, 09:34:57 pm »
Here is the spinner without an image file!
Code: QB64: [Select]
  1. _TITLE "Bplus Spinner 2020-07-19"
  2. RANDOMIZE TIMER 'B+ spinner 2020-07-19
  3. CONST xmax = 600
  4. CONST ymax = 600
  5. TYPE vectorType
  6.     x AS SINGLE
  7.     y AS SINGLE
  9. DIM SHARED wheel&
  10. SCREEN _NEWIMAGE(xmax, ymax, 32)
  11. _DELAY .25
  13. ca = _PI(2 / 36): wheelOffset = 6: dir = 1
  14. makeWheel
  16.     FOR a = 0 TO _PI(2) STEP _PI(2 / 36) ' give it a right quick start
  17.         CLS
  18.         RotoZoom2 _WIDTH / 2, _HEIGHT / 2, wheel&, 1, 1, -dir * a
  19.         LINE (295, 85)-STEP(10, 30), &HFFFFFF00, BF
  20.         _DISPLAY
  21.         _LIMIT 50
  22.     NEXT
  23.     stopAt = INT(RND * 36): i1 = 2: i2 = 1
  24.     FOR a = 0 TO _PI(2) + stopAt * ca STEP _PI(2 / 36)
  25.         CLS
  26.         PRINT i1, i2
  27.         RotoZoom2 _WIDTH / 2, _HEIGHT / 2, wheel&, 1, 1, -dir * a
  28.         LINE (295, 85)-STEP(10, 30), &HFFFFFF00, BF
  29.         'INPUT "OK ..."; w$
  30.         IF dir = 1 THEN
  31.             i2 = i2 + 1
  32.             IF i2 = 7 THEN i2 = 1: i1 = i1 + 1
  33.             IF i1 = 7 THEN i1 = 1
  34.         ELSE
  35.             i2 = i2 - 1
  36.             IF i2 = 0 THEN i2 = 6: i1 = i1 - 1
  37.             IF i1 = 0 THEN i1 = 6
  38.         END IF
  39.         _DISPLAY
  40.         _LIMIT stopAt + _PI(2) / ca - a / ca + 3
  41.     NEXT
  42.     IF RND < .5 THEN dir = -1 ELSE dir = 1
  43.     _DELAY 2
  45.
  46. SUB makeWheel
  47.     ca = _PI(2 / 36)
  48.     DIM vdigit(0 TO 35) AS vectorType
  49.     DIM outer(0 TO 35) AS vectorType
  50.     x0 = 190: y0 = 190: radius = 150
  51.     'CIRCLE (x0, y0), radius
  52.     COLOR &HFFFFFFEE
  53.     CIRCLE (x0, y0), 187
  54.     CIRCLE (x0, y0), 150
  55.     ca = _PI(2 / 36)
  56.     FOR i = 0 TO 35
  57.         xe = x0 + 187 * COS(i * ca + .5 * ca): ye = y0 + 187 * SIN(i * ca + .5 * ca)
  58.         IF i MOD 6 = 2 THEN
  59.             x = x0: y = y0
  60.         ELSE
  61.             x = x0 + 150 * COS(i * ca + .5 * ca): y = y0 + 150 * SIN(i * ca + .5 * ca)
  62.         END IF
  63.         px = x0 + 160 * COS(i * ca + .25 * ca)
  64.         py = y0 + 160 * SIN(i * ca + .25 * ca)
  65.         LINE (x, y)-(xe, ye)
  66.         IF i > 0 THEN
  67.             IF i MOD 2 THEN PAINT (px, py), &HFFFF0000, &HFFFFFFEE ELSE PAINT (px, py), &HFFFFFFFF, &HFFFFFFEE
  68.         END IF
  69.         IF INT(i / 6) > 0 THEN
  70.             px1 = x0 + 100 * COS(i * ca + .25 * ca)
  71.             py1 = y0 + 100 * SIN(i * ca + .25 * ca)
  72.             IF INT(i / 6) MOD 2 THEN
  73.                 PAINT (px1, py1), &HFFFF0000, &HFFFFFFEE
  74.             ELSE
  75.                 PAINT (px1, py1), &HFFFFFFFF, &HFFFFFFEE
  76.             END IF
  77.         END IF
  78.         '_LIMIT 5
  79.     NEXT
  80.     px = x0 + 160 * COS(i * ca + .25 * ca)
  81.     py = y0 + 160 * SIN(i * ca + .25 * ca)
  82.     IF i > 0 THEN
  83.         IF i MOD 2 THEN PAINT (px, py), &HFFFF0000, &HFFFFFFEE ELSE PAINT (px, py), &HFFFFFFFF, &HFFFFFFEE
  84.     END IF
  85.     px1 = x0 + 100 * COS(i * ca + .25 * ca)
  86.     py1 = y0 + 100 * SIN(i * ca + .25 * ca)
  87.     IF INT(i / 6) MOD 2 THEN
  88.         PAINT (px1, py1), &HFFFF0000, &HFFFFFFEE
  89.     ELSE
  90.         PAINT (px1, py1), &HFFFFFFFF, &HFFFFFFEE
  91.     END IF
  92.     FOR i = 0 TO 35
  93.         vdigit(i).x = x0 + radius * COS(ca * i - 2 * ca)
  94.         vdigit(i).y = y0 + radius * SIN(ca * i - 2 * ca)
  95.         'CIRCLE (vdigit(i).x, vdigit(i).y), 2
  96.         x = x0 + (radius + 18) * COS(ca * i - 2 * ca)
  97.         y = y0 + (radius + 18) * SIN(ca * i - 2 * ca)
  98.         IF i MOD 2 THEN c~& = &HFFFFFFFF ELSE c~& = &HFFFF0000
  99.         drwChar LTRIM$(STR$((i + 1) MOD 6 + 1)), c~&, x, y, 2, 2, ca * i - 2 * ca - _PI(1.5)
  100.         outer(i).x = x0 + (radius + r2) * COS(ca * i - 2 * ca)
  101.         outer(i).y = y0 + (radius + r2) * SIN(ca * i - 2 * ca)
  102.     NEXT
  103.     ca = _PI(2 / 6): radius = 80
  104.     FOR i = 0 TO 5
  105.         vdigit(i).x = x0 + radius * COS(ca * i - 2 * ca)
  106.         vdigit(i).y = y0 + radius * SIN(ca * i - 2 * ca)
  107.         'CIRCLE (vdigit(i).x, vdigit(i).y), 2
  108.         x = x0 + (radius + 18) * COS(ca * i - 2 * ca)
  109.         y = y0 + (radius + 18) * SIN(ca * i - 2 * ca)
  110.         IF i MOD 2 THEN c~& = &HFFFFFFFF ELSE c~& = &HFFFF0000
  111.         drwChar LTRIM$(STR$(i MOD 6 + 1)), c~&, x, y, 6, 6, ca * i - 2 * ca - _PI(1.5)
  112.         outer(i).x = x0 + (radius + r2) * COS(ca * i - 2 * ca)
  113.         outer(i).y = y0 + (radius + r2) * SIN(ca * i - 2 * ca)
  114.     NEXT
  115.     wheel& = _NEWIMAGE(380, 380, 32)
  116.     _PUTIMAGE (0, 0)-(380, 380), 0, wheel&, (0, 0)-(380, 380)
  118.
  119. SUB drwChar (char$, c AS _UNSIGNED LONG, midX, midY, xScale, yScale, Rotation) 'what ever the present color is set at
  120.     I& = _NEWIMAGE(8, 16, 32)
  121.     _DEST I&
  122.     COLOR c, &H00000000
  123.     _PRINTSTRING (0, 0), char$
  124.     _DEST 0
  125.     RotoZoom2 midX, midY, I&, xScale, yScale, Rotation
  126.     _FREEIMAGE I&
  128.
  129.
  130. SUB RotoZoom2 (X AS LONG, Y AS LONG, Image AS LONG, xScale AS SINGLE, yScale AS SINGLE, Rotation AS SINGLE)
  131.     DIM px(3) AS SINGLE: DIM py(3) AS SINGLE
  132.     W& = _WIDTH(Image&): H& = _HEIGHT(Image&)
  133.     px(0) = -W& / 2: py(0) = -H& / 2: px(1) = -W& / 2: py(1) = H& / 2
  134.     px(2) = W& / 2: py(2) = H& / 2: px(3) = W& / 2: py(3) = -H& / 2
  135.     sinr! = SIN(-Rotation): cosr! = COS(-Rotation)
  136.     FOR i& = 0 TO 3
  137.         x2& = (px(i&) * cosr! + sinr! * py(i&)) * xScale + X: y2& = (py(i&) * cosr! - px(i&) * sinr!) * yScale + Y
  138.         px(i&) = x2&: py(i&) = y2&
  139.     NEXT
  140.     _MAPTRIANGLE (0, 0)-(0, H& - 1)-(W& - 1, H& - 1), Image& TO(px(0), py(0))-(px(1), py(1))-(px(2), py(2))
  141.     _MAPTRIANGLE (0, 0)-(W& - 1, 0)-(W& - 1, H& - 1), Image& TO(px(0), py(0))-(px(3), py(3))-(px(2), py(2))
  143.
  144.
Logged

Offline SierraKen

  • Forum Resident
  • Posts: 1454
    • View Profile
Re: The Cobalt Spinner
« Reply #17 on: July 19, 2020, 09:42:31 pm »
Very cool B+. In the beginning I tried to make everything without files but I had no idea that PAINT could have a start and end color, until you just showed yours. LOL
Logged

Offline Cobalt

  • QB64 Developer
  • Forum Resident
  • Posts: 878
  • At 60 I become highly radioactive!
    • View Profile
Re: The Cobalt Spinner
« Reply #18 on: July 19, 2020, 10:09:49 pm »
And to think I was just goofing off! Wow this topic went farther than I had anticipated! XD


Well here have an animated gif I made with me own pics!

how odd, it doesn't act like an animated gif... should be.. is on my hard drive...???
not sure whats going on that should be 9 frames but its acting like a single frame when I test downloaded it. not sure whats up with that.


« Last Edit: July 20, 2020, 12:26:42 pm by odin »
Logged
Granted after becoming radioactive I only have a half-life!

Offline johnno56

  • Forum Resident
  • Posts: 1270
  • Live long and prosper.
    • View Profile
Re: The Cobalt Spinner
« Reply #19 on: July 20, 2020, 04:59:12 am »
Here's a wacky thought... What about using 'both' types of rotation. Disc in one direction and the arrow in the other... Talk about random...
Logged
Logic is the beginning of wisdom.

FellippeHeitor

  • Guest
Re: The Cobalt Spinner
« Reply #20 on: July 20, 2020, 12:32:18 pm »
Testing...





Logged

FellippeHeitor

  • Guest
Re: The Cobalt Spinner
« Reply #21 on: July 20, 2020, 12:35:02 pm »
Final test...


Logged

FellippeHeitor

  • Guest
Re: The Cobalt Spinner
« Reply #22 on: July 20, 2020, 12:35:34 pm »
Here, I used this corrupted GIF repair utility: https://ezgif.com/repair
Logged

Offline bplus

  • Global Moderator
  • Forum Resident
  • Posts: 8053
  • b = b + ...
    • View Profile
Re: The Cobalt Spinner
« Reply #23 on: July 20, 2020, 12:39:08 pm »
The gif is cool! but that comet doesn't look right?
Logged

Offline Cobalt

  • QB64 Developer
  • Forum Resident
  • Posts: 878
  • At 60 I become highly radioactive!
    • View Profile
Re: The Cobalt Spinner
« Reply #24 on: July 20, 2020, 05:30:36 pm »
Quote from: bplus on July 20, 2020, 12:39:08 pm
The gif is cool! but that comet doesn't look right?

How so?

I have over 100 images I took Thursday. I'm going to try and gif together, but I will probably turn it into a video and upload it to YT instead. as for some reason the forum don't like my gifs. and it will be several megs in size.
Logged
Granted after becoming radioactive I only have a half-life!

Offline bplus

  • Global Moderator
  • Forum Resident
  • Posts: 8053
  • b = b + ...
    • View Profile
Re: The Cobalt Spinner
« Reply #25 on: July 20, 2020, 05:35:42 pm »
I was expecting comet tail to follow the direction it's going (why else call it a tail?) but I guess it always points away from the sun. Learn something new...

Logged

Offline johnno56

  • Forum Resident
  • Posts: 1270
  • Live long and prosper.
    • View Profile
Re: The Cobalt Spinner
« Reply #26 on: July 20, 2020, 06:44:02 pm »
Comets usually follow long elliptical orbits. The "tail" does not normally show until it nears the Sun. Although the "body" of the comet follows the orbit, the tail, being less in mass, is influenced by 'Solar Wind' and as a result, the 'tail' will point away from the Sun. So therefore, when you see a comet, the 'tail' will indicate the direction of the Sun and not the direction that the comet is traveling. I hope this helps.
Logged
Logic is the beginning of wisdom.

Offline bplus

  • Global Moderator
  • Forum Resident
  • Posts: 8053
  • b = b + ...
    • View Profile
Re: The Cobalt Spinner
« Reply #27 on: July 20, 2020, 06:50:38 pm »
OK now about the UFO in one frame?

What's the scientific explanation for that? Elmo's Fire?

Logged

Offline Cobalt

  • QB64 Developer
  • Forum Resident
  • Posts: 878
  • At 60 I become highly radioactive!
    • View Profile
Re: The Cobalt Spinner
« Reply #28 on: July 20, 2020, 07:45:10 pm »
Lightning Bug. :D

Several of my Thursday batch have nice glowing trails cause the exposure time was ~20 seconds so any light that happens to flash in the sky gets caught to some degree. have some satellite trails too. missed the shooting star I saw Thursday, go figure! Supposed to be a bit of a meteor shower next week around the 28th I believe to be the highlight night.

Camera will only take up to 10 consecutive shots at a time, which takes just around 4-4 1/2 mins to complete so depending on conditions I might just catch one. but the comet was my highlight this year.
In 2024 when the solar eclipse passes over head I will be in the path of totality, for about 3:33 secs, or I could drive about 15 miles north and be in the center of the path! Hoping to have a telephoto lens for that one and catch the corona.

As for the static red, white, and blue dots, I'm not sure. Something tells me the sensor in my camera may be slightly damaged maybe? they don't really show in daylight photos, mainly just night shots.
« Last Edit: July 20, 2020, 07:47:46 pm by Cobalt »
Logged
Granted after becoming radioactive I only have a half-life!

Offline bplus

  • Global Moderator
  • Forum Resident
  • Posts: 8053
  • b = b + ...
    • View Profile
Re: The Cobalt Spinner
« Reply #29 on: July 20, 2020, 10:15:55 pm »
LOL a lightning bug! Of course.
